Rii k01v3 mini wireless keyboard backlit laser pointer for Multimedia

Product Description with laser pointer with backlit keyboard&touchpad combo Rii mini wireless keyboard Model RT-MWK01 Country/Region of Manufacture China Interface RF Receiver dongle inside the keyboard when take off the back cover EAN 6952917701003 Can’t be used on SAMSUNG SMART TV/HISENSE UHD SMART TV Connectivity Wireless Can’t be used on TABLET AND IPAD(no OTG interface) Type Mini Keyboard/Keypad Keyboard MPN 69529177 Brand Rii Keyboard Layout US Color Black

　

　

Why Choose us?

　

1.Riitek authorized seller. Genuine assurance!

2.Arrange shipping in 1 business day!Shipping from US stock.
3.Standard Int’l Shipping. Registed mail with tracking number.

4.Professional technical support and the best after-sales service

　



Why choose mini wireless keyboard rii mini k01v3 ?

Features:



* 2.4G Wireless Receiver Integrated Design

* Backlit (26 LED) Function with aHandheld Keypad

* 90-degree Flip Touchpad

* Innovative Design of the Navigation Keys

* Windows Multimedia Control

* Build-in Large Capacity RechargableLi-ion Battery: 600mA

* Laser Pointer

* With a Real Notebook Touchpad

* Real QWERT full-function Mini Keyboard

* A Perfect Keyboard for your For Windows& Mac OS PC, HTPC, IPTV,

  PS3 & Xbox 360 etc.

* Portable, Elegant, Lifestyle

　

　



　

　

　

　

　

　



NOTE:

THIS RF KEYBOARD DOESN'T WORK ON SAMSUNG SMART TV /

HISENSE UHD SMART TV / TABLET AND IPAD.



　





Product details:

Receiver(dongle)

Nano style

Connect port

With USB1.1 above

Processor(MCU)

BK2433 Serials

Transmit mode

2.4GHz wireless

Transmit Power

Less than +4db

Power  supply

Rechargeable 450mAh polymer Lithium-ion battery

Charging voltage

4.4V ~ 5.25V

Charging current

300mA

Sleeping Current class1

0.8mA

Operation Voltage



3.7V











Operating Current

<60mA

Product weight

100g

Product Size

151mm*59mm*12.5mm

Color

Black

Accessories

USB cable for charging

1pcs

Nano dongle

1pcs

User manual

1pcs

　

　

　

　

　

　

　



　

　

　

　

　

　

　

　

　

RFQ

　

　

1.Q:Does Rii wireless K01V3 work well with my device?

　

 A:My friend, honestly to say, we’re not sure, since we don’t test it on every device.:)
Maybe you could test it first by yourself follow below method:
You could use a common wired keyboard with USB port and mouse on the device.
If they both work well, this item can work on the device, too .
If the device don’t support wired keyboard and mouse, we suggest you don’t buy this keyboard.:)

2.Q:where is the dongle ? there is no dongle on the parcel.



 A:My friend,the dongle is inside the keyboard when you receive the item .

　

　

　

3.Q: Why the RF keyboard doesn't work on my computer? Its yellow light flashes.

A: For RF keyboards, yellow light flashing means the keyboard fails to connect with your

computer, not the quality problem.Now you just need to repair the keyboard with thedongle.

Repair steps:(only for the Rii mini keyboard without air mouse function,like Rii mini k01x1,  Rii mini i8, Rii mini i8+, Rii mini k01v3 etc.)

Step1: Keep your PC on.

Step2:Press the “F1” without releasing.

Step3:Power on the keyboard and release the "F1" immediately.

Step4:Plug the USB receiver on the USB port of your PC.

Wait a moment. The keyboard will repair automatically.

When the yellow light stop flashing, it means repair successfully.

Then you could try if it works well.

If you still have any doubt, pls contact our customer service with no hesitate.

We're here to serve you best.

4.Q: How to make the backlight of Rii mini K01V3 keep light?

 A: Press Fn+F1 after the keyboard connect with your device.

If you don’t use it in 1 minute, the backlight will go off. You could press any key to light the backlit.

　

　

4.Q: Why the key of Rii mini k01v3 repeat, when press once,

   typing many letters, like press”a” , output ’aaaaaa’?

A: This situation sometimes happens when the 2.4G RF keyboard is used on smart TV.

Using the keyboard on smart TV, and plugging the USB dongle directly in the USB port behind the TV,

this could lead to the the signal of the keyboard and dongle be interfered by the TV.

You could connect the USB dongle and the TV with an extension cord to solve this problem

IN THE BOX:

Keyboard

USB Charging Cable
USB Receiver
User Manual
